| 사 양 |
| Overall Dimension 325 x 262 x 132mm |
| Total Weight (Including 1 batt.) 5.5Kg |
| 1024 x 768 pixels 10.4" Touchscreen with multi-touch capabilities |
| 32/128 with PR mode to truly benefit from Transmit-Receive |
| Dedicated Conventional UT pulsers : 2 pulse-echo or 2 pitch & catch (TOFD) |
| Compact and rugged casing with no air intake |
| Up to 512 different focal laws |
| Data file size:Up to 700MB |
| Data acquisition rate up to 10MB/s |
| Embedded 120GB solid-state drive (SSD) |
| 8-bit or 16-bit amplitude resolution of phased array signal |
| High-quality PA UT probe connector with latch |
| Automatic probe detection |
| Encoder interfaces : 2 quadrature-type |
| Excitation pulse PA UT : Up to 75V (on 50Ω ) load |
| Excitation pulse UT : Up to 200V (on 50Ω ) load |
| Digitization frequency : 100MHz (compression available) |
| Max. timebase length : 8,192 samples and over 200,000 points evaluated |
| |
| Softgain 32dB 증가시 데이터 비교 |
 |
|
 |
| 16-bit Data |
|
8-bit Data |
| 32/128PR with 2UT channels(TOFD) |
|
UltraVision 3 data files format up to 700MB |
| Up to 512 focal laws |
|
Storage:120GB SSD |
| 1 synchro gate + 4 detection gates |
|
10.4" multi-touch display |
16-bit amplitude resolution
(Up to 48dB soft gain or 800% FSH) |
|
Resolution:1024 x 768 pixels |
|
High-quality ZIF connector with latch |
