| 1) ELECTRICAL |
|
| 사용 전압 |
|
90- 245 V /45-66Hz |
| Measure of kV and mA |
|
True measure |
|
| 2) Embedded Software |
|
| 분류 |
|
내용 |
| Main screen |
|
Selector mode, settings and controls |
| kV step |
|
1-2 - 5 kV |
| mA step |
|
0.1 -0.2 - 0.5 mA |
| Memories |
|
10,000 with user directories |
| Modes |
|
Standard user, Supervisor, SAV |
|
| 3) Connections / Environmental |
|
| 분류 |
|
내용 |
| Generator connector |
|
Sub-D62 |
| Device connector |
|
1 x USB 2.0 |
| 사용온도 |
|
-5°C to 50°C |
