| 분류 |
|
내용 |
| 크 기 |
|
356 mm x 115mm x190mm(battery pack 포함) |
| 무 게 |
|
5.4kg(battery pack 포함) |
| Output dose |
|
4.0 mR/pulse max, 2.6 mR/pulse min, measured 12 inches from source |
| Pulse rate |
|
15 pulse per second nominal |
| X-ray source 크기 |
|
13 mm |
| Maximum photon energy |
|
270 KVP |
| X-ray pulse width |
|
50 nanoseconds |
| Current draw |
|
20 amps @ 13.4 volts |
| 전원 |
|
DeWalt® 14.4V, removable, Ni-Ca 충전용 배터리 |
| 배터리 충전 시간 |
|
1 hour with standard DeWalt® charger, 15 minute charger available |
Number of pulses
per battery charge |
|
4000 |
| 사용 온도 |
|
-23C to 50C |
| Maximum duty cycle |
|
200 pulses every 4 minutes (3000 pulses per hour) |
| Warm-up |
|
None required |
| X-ray leakage |
|
3 mR per 100 pulses measured 2 inches behind the unit |
| Warranty |
|
1 year limited warranty |
