MultiRad 160 |
|
MultiRad 225 |
|
MultiRad 350 |
| Energy range |
|
∼160 kV |
|
∼225 kV |
|
∼350 kV |
| Tube current |
|
18.7 mA |
|
13.3 mA |
|
11.4 mA |
| Tube power |
|
3 kW |
|
3 kW |
|
1 kW |
| Focal spot size (EN) |
|
5.5 mm |
|
5.5 mm |
|
8.0 mm |
| Focal spot size (IEN) |
|
0.4 mm for imaging |
|
|
|
|
| Inherent filtration |
|
0.8 mm beryllium |
|
0.8 mm beryllium |
|
3 mm beryllium |
| X-ray beam angle |
|
40º divergence |
|
40º divergence |
|
40º divergence |
| Maximum coverage |
|
28" (72 cm) |
|
28" (72 cm) |
|
28" (72 cm) |
| Weight |
|
960 kg |
|
1160 kg |
|
1575 kg |
| Shipping weight |
|
1550 lbs. (705 |
|
1550 lbs. (705 |
|
1550 lbs. (705 |
| Beam coverage range |
|
90mm - 400mm diameter |
| Source to sample range |
|
130mm - 650mm |
| Power requirements |
|
220 VAC ±10%, 50/60 Hz 2000 VA max |
| Exposure time |
|
programmable or continuous |
| Cooling |
|
Integrated closed-loop heat exchanger |
| Specimen turntable |
|
Electrically operated, 2 RPM |
| Chamber dimensions |
|
580mm x 410mm x 430-mm |
| External dimensions |
|
1880mm x 1080mm x 880mm |
