| General Specifications |
| 크기 |
29.7cm x 10.7cm x 32.5cm |
| 무게 |
배터리 장착 시 6.7kg, 배터리 탈착 시 5.8kg |
| 배터리 |
약 8시간 작동, 충전 가능한 리튬이온 배터리 |
| 전압 |
115/230 VAC |
| 컴퓨터 인터페이스 |
LAN 10 / 1000 Base T |
| 작동 온도 |
-5˚C to 45˚C |
| 보관 온도 |
-20˚C to 60˚C |
| Eddy Current (ECT) |
| Probe Inputs |
8 |
| Number of Frequencies |
Up to 160 |
| Frequency Range |
5Hz - 4MHz |
| Generators |
2 |
| Coil Drivers |
3 (1 is for French probes only) |
| Generator output |
Up to 20 Volts peak-to-peak |
| Injection modes |
Continuos and Super-Multiplex |
| Receiver gain |
23-58dB, 35dB range |
| ADC resolution |
16 bits |
| Connector |
36-pin circular for X-probes and MRPC probes
4-pin for bobbin with adapter #10038239
6-pin for French with adapter #009A801-00
Two 4-pin for AC3 with adapter #009A802-00
8-pin for MFL with adapter #009A804-00 |
| Low-Voltage Remote Field Testing (RFT) |
| Probe Inputs |
4 |
| Number of Frequencies |
5 |
| Frequency Range |
5Hz - 250KHz |
| Generator/Coil Driver |
2 |
| Generator Output |
Up to 20 volts peak-to peak |
| Injection modes |
Continuous |
| Receiver gain |
36-86dB, 50dB range |
| ADC resolution |
16 bits |
| Acqusition/sampling rate |
Up to 40,000 per second |
| Connector |
19-pin circular |
| Manetic Flux Leakage (MFL) |
| Probe Inputs |
4 |
| Receiver gain |
20-58dB, 38dB range |
| ADC resolution |
16 bits |
| Acquisition/sampling rate |
Up to 40,000 per second |
| Connector |
36-pin circular,
8-pin with adapter #009A804-00 |
| Eddy Current Array (ECA) |
| Probe Inputs |
128 |
| Probe Outputs |
128 |
| Number of Frequencies |
Up to 160 |
| Frequency range |
5Hz - 4MHz |
| Generator Coil driver |
2 |
| Generator output |
Up to 20 volts peak-to-peak |
| Injection modes |
Continuous and Super-Multiplex |
| Receiver Gain |
23-58dB, 35dB range |
| ADC resolution |
16 bits |
| Acquisition/sampling rate |
Up to 40,000 per second |
| Multiplexer |
Internal, configures MIZ-200 to match the probe coil arrangement (differential, absolute, driver-pickup, transmit-receive, differential driver-pickup |
| Connector |
160-pin rectangular |
| Motor Drive for MRPC Probes |
| Speed Regulation |
Regulation of probe rotating speed to provide constant speed under varying loads |
| Output Current |
2.7A continuous |
| Maximum Power |
35 Watts continuous |
| Connector |
36-pin circular |
