사 양 |
| Test Method |
|
Multi-frequency delector-magnetic testing in multiplexed and simultaneous injection(SI)
mode.
- Multiplexed mode : supports 4 test frequencies
- SI mode : Up to 4 frequencies or up to 8 coil pairs |
| Dimension |
|
203 x 292 x 343mm |
| Weight |
|
7.3Kg |
| Power |
|
85-264VAC, 47-63Hz |
| Operating Temp. Range |
|
0 ~ 45℃ |
| Storage Temp. Range |
|
-40 ~ 85℃ |
| Frequency Range |
|
5Hz - 10MHz |
| Display |
|
Color 640 x 480 pixel |
| Drive |
|
0 - 20Vpp |
| Sample Rate |
|
- Multiplexed mode : up to 15,600s/s for 1 frequency 3,900s/s for 4 frequencies
- SI mode : up to 15,600 s/s at 4 frequencies |
| Memory |
|
- 40GB internal hard dirve
- Flash memory for configuration and firmware updates
- Non-voltages via USB memory for storage of instrument stetting. |
| Input/Output |
|
- Ethernet 10/100 based T for netwark interface
- VGA-output display to VGA monitor or video output with external converter box
- RS232 communication to mode |
